RCF EVOX 12 ACTIVE TWO-WAY ARRAY
EVOX 12 is the most powerful line-source in its class and offers a particularly profound and dynamic reproduction at high levels due to the built-in 1400W power amplifier. The top section has eight high performance neodymium 4 “full-range transducers with a phase plug. As a result, the EVOX 12 has a significantly increased low-mid playback at a constant level with a wide dispersion for the highs. The 15” sub woofer delivers powerful bass sound to reinforce a big party or the kick drum of a live band. Despite high performance, the enclosure is very compact, and thanks to integrated wheels and extendable handle very easy to transport.
Frequency Response:40 Hz ÷ 20000 Hz
Max SPL @ 1m:130 dB
Horizontal coverage angle:90°
Vertical coverage angle:30°
Transducers
Fullrange:8 x 4.0”, 1.0” v.c
Woofer:15”, 3.0” v.c
Input/Output section
Input signal:bal/unbal
Input connectors:XLR, Jack
Output connectors:XLR
Input sensitivity:-2 dBu/+4 dBu
Processor section
Crossover frequencies:180 Hz
Protections:Thermal, RMS
Limiter:Soft Limiter
Controls:Volume, EQ
Power section
Total Power:1400 W Peak, 700 W RMS
High frequencies:400 W Peak, 200 W RMS
Low frequencies:1000 W Peak, 500 W RMS
Cooling:Convection
Connections:VDE
Standard compliance CE marking:
Yes
Physical specifications
Cabinet/Case Material:
Baltic birch plywood
Color:Black
